Stage Size: 68' x 36'

Stage Right Wing:  22' x 37'

Stage Left Wing:  19' x 35'

Thrust:  10' at C from stage; 6' SR and SL from stage



Dock Size:  15' x 115' (it will accommodate 53' Truck with sleeper cab, or tour bus with large trailer

Dock Lift:  6' x 8' (5,000 lb. capacity; 5' vertical travel)

Outside Roll Up Door:  8' x 13' to interior room (21' x 19')

Inside Roll Up Door:  8' x 13' to stage



Stage Power:  (3) 400 amp 3 phase 120/208  Stage Right

FOH Power:  (1) 20 amp circuit

Shore Power:  None



Fly Rail:  29 line sets (16 free) (1500lbs arbor capacity) (70' battens) (53' out position)

Soft Goods:  Main Teaser - LS 1 (fixed position)

  Main Drape:  LS 2 (fixed position)

  1st Border:  LS 7

  1st Leg:  LS 8

  2nd Border:  LS 13

  2nd Leg:  LS 14

  3rd Border:  LS 18

  Midstage Traveller:  LS 19 (fixed position)

  4th Border:  LS 22

  4th Legs:  LS 23

  Upstage Black:  LS 28 (fixed position)

Rigging Points:  Audio - 2'6" from PL 27'8" R & L of Center

      Point- 3' 10" from PL, Points at C,R,L at 11' & 22' from center

      Point- 9' 10" from PL, Points at C,R,L at 22' from center

      Point- 14' 10" from PL, Points at C,R,L at 18' from center

      Point- 19' 5" from PL, Points at C,R,L at 22' from center

      Point-  23' 0" from PL, Points at C,R,L at 18' from center

      Point- 26' 4" from PL, Points at C,R,L at 22' from center





FOH:  56 ETC Source lekos with 19 and 26 degree barrels

Onstage:

      1st Electric:  3' 4" from PL, 30 ETC Source Four PARnels

      2nd Electric:  9' 4" from PL, 30 ETC Source Four PARnels

      3rd Electric:  16' 0" from  PL, 30 ETC Source Four PARnels

      4th Electric:  25' 4" from PL, 6 Colortran 3 cell cyc lights





(1) Stage Right with bathroom (women's)

(1) Stage Left with bathroom (men's)

There are (2) additional rooms adjacent to the dressing rooms which may be used as extra dressing space or production office.

For large dance competitions and recitals; there is a large cafeteria down the hall from the lobby which can be used for dressing room.  There are (2) lavatories (boys and girls) adjacent to the cafeteria.



Capacity:  approx. 2350  (1750 on the first floor; and 600 in the balcony)

Staffing:  IATSE Local 8 Stagehands; not included in rent

Ushers:  Volunteers

Parking Lot/Security:  (2) WTPS security; not included in rent

Custodians: not Included in rent

Fire Marshal:  (2) per event; not included in rent

Ticketing:  Ticketmaster; included in rent
